UV Adhesive for Glass & Metal – High Bonding Strength with Optical Clarity
The Challenge of Bonding Glass to Metal — Solved with UV Adhesive
ZDS™ solves this challenge with UV-curable adhesives that provide:
- ✅ Strong, flexible adhesion across glass, aluminum, stainless steel, and other metals
- ✅ Crystal-clear bonds that enhance product appearance
- ✅ Instant curing with UV/LED light for fast production cycles
- ✅ Solvent-free, clean application with no residue or bubbling
- ✅ Excellent weather, thermal, and chemical resistance
ZDS UV Adhesive for Glass & Metal
Model
Appearance
Viscosity /cps
Curing energy mj
Details
- ZDSCD2108204 Model lamp bead glue
- Transparent or yellowish liquid
- 3000~3400
- 400-800mj£»365 point light source
Need help choosing the right adhesive?
Just share your needs with us — our experts will match you with the best solution. Click the button below to get started.
Applications of UV Adhesive for Glass & Metal
ZDS™ UV adhesives for glass and metal are widely used in industries that demand both structural performance and visual excellence:
Glass Furniture Assembly
Bond glass table legs to metal frames without screws or brackets. Achieve seamless joints that withstand pressure and thermal cycling.
Architectural & Interior Design
Perfect for modern bathroom mirrors, shower enclosures, balustrades, and glass wall panels attached to steel or aluminum fittings.
Electronics & Consumer Products
Used to attach glass displays or covers to metal casings in devices such as smart speakers, LED fixtures, or control panels.
Artware & Displays
Invisible bonding of decorative glass to metal stands or frames, ideal for museums, exhibitions, and luxury goods.
Advantages of ZDS™ UV Adhesive for Glass & Metal
Superior Bond Strength
Formulated to handle the differences in thermal expansion between glass and metal, ensuring long-term durability under temperature changes and mechanical stress.
Optical Transparency
Provides a crystal-clear finish, making it the go-to solution for high-end visual products like displays, fixtures, and glass décor.
Fast Curing
Cures in seconds under UV or LED light, speeding up production without the need for clamping or prolonged drying times.
Weather & Moisture Resistance
Withstands exposure to humidity, UV sunlight, and temperature fluctuations—ideal for indoor and outdoor use.
No Discoloration Over Time
UV stable and resistant to yellowing, ensuring that the joint maintains its clarity even after years of use.
Clean, Non-Drip Application
Medium viscosity ensures controlled application without running, ideal for vertical or curved bonding surfaces.
Technical Specifications
- UV Cure Energy: 800–1200 mJ/cm²
- Full Cure Time: 5–10 seconds depending on lamp intensity
- Storage Conditions: 5–25°C in a cool, dry place
- Packaging Options: 30ml / 50ml / 250ml syringe or 1kg bulk pack
- Shelf Life: 9–12 months
- Compliance: RoHS / REACH / Halogen-free
How to Use UV Adhesive on Glass & Metal
- Surface Preparation: Clean both glass and metal surfaces with isopropyl alcohol or acetone to remove oils, dust, and particles.
- Apply Adhesive: Dispense a thin, even layer of ZDS adhesive onto the bonding area. Avoid excess to prevent overflow.
- Align Components: Press the parts together with light pressure. Ensure perfect alignment before curing.
- Cure with UV Light: Use a 365–405nm LED UV light source for 5–10 seconds until fully cured.
- Post-Cure Inspection: Check for bubble-free, even bonding. Load testing or thermal cycling tests may be conducted if needed.
Who Should Choose ZDS™ UV Adhesives?
We serve a wide range of industries and product manufacturers:
- 📐 Glass furniture makers
- 🛠️ OEM hardware and appliance companies
- 🖼️ Luxury display and packaging brands
- 🧰 Architectural construction firms
- 🔧 Precision electronics and control device manufacturers
If you need aesthetically clean, long-lasting, and fast adhesive solutions for glass-metal joints, ZDS™ is your best partner.
Frequently Asked Questions
Will this adhesive yellow over time?
No. ZDS UV Adhesives is UV stable and engineered to remain clear and colorless over time.
Does it work on frosted or treated glass?
Is the adhesive flexible after curing?
Can I use this for outdoor applications?
Do you offer customized formulations?
What Customers Are Saying
Request a Free Sample or Custom Solution
- 🔍 Free product samples
- 🧪 Application consultation
- 📄 Technical datasheets and certifications
- 📦 Bulk pricing and delivery support
